R10L210-MRM2

10.4″ Marine Display R10L210 certified for maritime DNVGL-CG-0339, IEC60945 4th, IACS E10, Enhanced shock and vibration resistance.

Features and Benefits

  • 10.4″ 800 x 600 resolution Marine Display
  • Resistive touch screen (Optional protection glass w/o touch function)
  • IP66 aluminum housing with powder coating design (IP54 rear)
  • 24 V DC power supply with terminal block (Default, isolation resistance)
  • Picture-in-picture (PIP) function and multi-video inputs
  • Ease-of-use front panel OSD control
  • Enhanced shock and vibration resistance
  • Certified DNVGL-CG-0339, IEC60945 4th, IACS E10
  • Dimming knob to control backlight brightness from nearly 0% to 100%

IACS-E10IEC60945DNVGL-CG-0339FCCCE

Available to Order
WhatsApp Us
Get Quote Get Quote
Download Datasheet Download Datasheet

Models

  • R10L210-MRM2

Overview

How to Buy

Click “WhatsApp Us” or “Get a Quote” above to buy R10L210-MRM2 from APulsar Technologies, WINMATE official partner.

Winmate Marine Display Series provides reliable and durable performance for maritime environments, available in sizes from 10.1″ to 24″. Certified with DNVGL-CG-0339, IEC60945 4th, and IACS E10 standards, these displays ensure compliance with marine industry requirements. Featuring an IP66 aluminum housing with powder coating (IP54 rear), a dimming knob for precise backlight control, and enhanced shock and vibration resistance, they are built for harsh conditions. With optional touchscreen or AR protection glass, multi-video inputs, and user-friendly front panel OSD controls, these displays are ideal for navigation and control applications.

Specifications

Display

Resolution

  • 800×600

Size

  • 10.4 inches

Contrast Ratio

  • 400:1

Panel Brightness

  • 600.0 nits

Display Color

  • 262K Colors

View Angles

  • 70,70,70,60

Active Area

  • 211.2×158.4 mm

Touch / Glass

  • Resistive Touch Screen (Default)
  • AR Glass (Optional)

Operating Humidity

  • 5% to 95%

Operating Temperature

  • -15~55°C

Shock

  • 15G,11ms duration

Vibration

  • 0.7g@DNV-CG-0339 (Class A)

IP rating

  • IP66 (Front Side)

Certification

  • CE, FCC
  • DNV-CG-0339, IEC60945 4th, IACS E10

Serial Port

  • 1 x RS232 for Remote Control
  • 1 x RS232/USB for Touch Screen

Video

  • 1 x VGA
  • 1 x DVI-D
  • 1 x Composite
  • 1 x S-Video

Dimension

  • 339 x 256 x 72 mm

Weight

  • 3.7 kg

Mounting

  • VESA mount/Panel mount

Enclosure

  • Metal Housing with Aluminum Bezel

Cooling System

  • Fanless Design

Cut out

  • 300 x 232 mm

Power Rating

  • 24V DC-in with Isolation (Approval by Certificate)
  • 9~36V DC Input Acceptable

Consumption

  • 25W (Typical)

Accessory

  • 1 x User Manual.
  • 1 x DVI Cable.
  • 1 x VGA Cable.
  • 1 x RS232 Serial Cable.
  • 1 x S-Video Cable.
  • 1 x Composite Cable.
