WAC-M300 Series

Features and Benefits

  • 2-in-1 AP controller and mobile IP home agent
  • Millisecond-level controller-based Turbo Roaming
  • IEEE 802.11i compliant wireless security
  • Scalable tunneling capacity
WhatsApp Us
Get Quote Get Quote
Download Datasheet Download Datasheet

Models

  • WAC-M300

Overview

How to Buy

Click “WhatsApp Us” or “Get a Quote” above to buy EDS-2005-ELP from APulsar Technologies, MOXA official distributor.

Purchase walk-in from our office in Petaling Jaya, or order online and enjoy fast delivery across Kuala Lumpur and the entire Malaysia.

Introduction

The goal of fast roaming capability is to allow clients to maintain their communications as they move from one access point to another. Moxa’s WAC-M300 Series advanced wireless access controller with controller-based Turbo Roaming technology enables millisecond-level roaming between different IP subnets. The advanced roaming algorithm combined with Mobile IP technology allows seamless roaming while maintaining stringent security in demanding network scenarios. The rugged WAC-M300 Series is rated to operate in temperatures of 0 up to 50°C and suitable for on-site installation in harsh industrial environments..

Maximum Availability

  • Device-level redundancy via hot standby controller

Minimum Handover Time

  • Millisecond-level Turbo Roaming
  • Inter-controller roaming

Specifications

Ethernet Interface

10/100/1000BaseT(X) Ports (RJ45 connector)

  • 2
  • Port 1: Communications port for WAC/HA
  • Port 2: Reserved

Standards

  • IEEE 802.11i for Wireless Security
  • IEEE 802.3 for 10BaseT
  • IEEE 802.3u for 100BaseT(X)
  • IEEE 802.3ab for 1000BaseT(X)
  • IEEE 802.1X for authentication

Management

  • IPv4
  • SNMPv1/v2c/v3
  • TCP/IP
  • Telnet
  • Web Console
  • Wireless Search Utility
  • MXconfig
  • MXview One

Security

  • HTTPS/SSL
  • RADIUS
  • SSH

Time Management

  • NTP Client
  • SNTP

Console Port

  • RS-232 ports x 1 (DB9 male)

Flow Control

  • RTS/CTS, XON/XOFF

Parity

  • None, Even, Odd, Space, Mark

RS-232

  • TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND

Controller Failover Mode

  • 1-on-1 hot backup

Handover Time

  • 50 ms

Roaming Support

  • Turbo Roaming (L2) with inter-controller capabilities

WLAN Products Supported

  • Layer 2 networks: Up to 190 clients roaming between 400 APs

TAP Products

  • TAP-M310R Series

Input Current

  • 1.2 A @ 100 VAC

Input Voltage

  • 100 to 240 VAC

No. of Power Inputs

  • 2

Operating Voltage

  • 100 to 240 VAC

Housing

  • Metal

Dimensions (without ears)

  • 304 x 440 x 44 mm (11.97 x 17.32 x 1.73 in)

Weight

  • 5,480 g (12.08 lb)

Installation

  • 19-inch rack mounting

Operating Temperature

  • 0 to 50°C (32 to 122°F)

Storage Temperature (package included)

  • -40 to 85°C (-40 to 185°F)

Ambient Relative Humidity

  • 5 to 95% (non-condensing)

Safety

  • UL 62368-1
  • EN 62368-1
  • IEC 62368-1

EMC

  • EN 55032/35
  • EN 61000-6-2/-6-4

EMI

  • CISPR 32, FCC Part 15B Class A

EMS

  • IEC 61000-4-2 ESD: Contact: 8 kV; Air: 15 kV
  • IEC 61000-4-3 RS: 80 MHz to 1000 MHz: 20 V/m
  • IEC 61000-4-3 RS: 1400 MHz to 2000 MHz: 10 V/m
  • IEC 61000-4-3 RS: 2000 MHz to 2700 MHz: 5 V/m
  • IEC 61000-4-3 RS: 5100 MHz to 6000 MHz: 3 V/m
  • IEC 61000-4-4 EFT: Power: 4 kV; Signal: 2 kV
  • IEC 61000-4-5 Surge: Power: 2 kV; Signal: 1 kV
  • IEC 61000-4-6 CS: 10 V
  • IEC 61000-4-8 PFMF: 100 A/m

Green Product

  • RoHS, CRoHS, WEEE

Time

  • 770,346 hrs

Standards

  • Telcordia Standard SR-332

Warranty Period

  • 5 years
